ITEM                        项目　　

UNIT单位

KS88T

Clamping Force                   锁模力

kn

880

Opening Force                    开模力

㎏　　

2900

Clamping Stroke                 锁模行程

㎜　

250

Ejector Force                     顶出力　

kn

52

Ejector Stroke                   顶出行程

㎜　

60

Mould thickness             模具厚薄距离

㎜　

150-360

Moulding board size              模板尺寸

㎜　

565*545

Lnner space between tiebbbar    哥林柱内距　　

㎜　

360*360

Tiebar diameter                哥林柱直径

㎜　　

65

Lnjection place                  射料位置

㎜

0-60

Lnjection force                    射料力

kn

65

Lnjection stroke                 射料行程

㎜

130

Lnjection stroke                   射料量

㎏

1.25/1.60

Hammer diameter                锤头直径

㎜

50/55

Traverse stroke                  离嘴行程

㎜　　

195

Working pressure                工作压力

Mpa　

10.5

Driving Motor                   马达功率　　

KW

11

Crucible Capability               坩锅容量　

L(㎏/Zn)　

55(360)

Puel oll                            燃油　

kg/h

4

Electric cooker                      电炉

kw

32

Oil box capability                油箱容量　

L

250

Machine weight                     机重　

kg

3900

Overall dimension              机身总尺寸

㎜　　

4250*1550*2155
